Mean Well MW SE-450-36 36V 12.5A 450W AC/DC Switching Power Supply

Mean Well
Part #320-3144

Mean Well MW SE-450-36 36V 12.5A 450W AC/DC Switching Power Supply

Mean Well
Part #320-3144
Model: SE-450-36
This large 36 volt DC, 12.5 amp regulated power supply is capable of up to 450 watts of output. Switchable 90-264 volts AC input. UL recognized design.
Key Features
  • Adjustable 33 to 39 VDC regulated output with 12.5A current capacity
  • AC input active surge current limiting reduces AC noise
  • AC input range selected by switch for domestic and international applications
  • Overload, over voltage, and over temperature protection built-in
  • Forced air cooling by built-in DC ball bearing fan
  • Built-in remote sense function
  • UL 60950-1 approved for safety
Your Price: $99.98
+ FREE SHIPPING
MSRP: $152.99
Save $53.01 (35%)
Bulk Pricing
Quantity:Qty: 1-3 $99.98/ea
Quantity:Qty: 4+$93.82/ea
Order in the next 1 hr 2 min to ship today. Details

In Stock

Free Shipping available on orders over $99.00 in the US. Details

Overview

Mean Well MW SE-450-36 36V 12.5A 450W AC/DC Switching Power Supply

This beast of a power supply is ideally suited for use with amplifier projects. With a regulated output of 36 volts DC, and current capacity of 12.5A amps, this power supply is the perfect partner for amplifier boards with of up to 450 watts of output on tap.

Voltage input can be switched for use with 110 or 240 VAC mains power. Overload, over voltage, and over temperature protection is built-in, shutting down the power supply to prevent damage and then restoring power upon recovery. Forced air cooling regulates temperature internally. Power cable included. UL recognized design. Output voltage is adjustable from 32 to 40 VDC.

Note: Minimum recommended power wire is 16 AWG.

Specifications: • Input power: Switchable between 90-132 VAC and 180-264 VAC, 47-63 Hz • Output power: 36 VDC, 12.5A • Dimensions: 8.85" L x 4.75" W x 1.97" H • Includes: 5 ft. AC cord and 3 ft. DC cord with 2.1 x 5.5 mm plug.

Product Details

BrandMean Well
ModelSE-450-36
Part Number320-3144
Unit of MeasureEach
Weight3.25

Product Specifications

DC Output Voltage36V
Input Voltage110/220 VAC
