  • Lanzar MAX15D 15" Pro Woofer DVC 4 Ohms per Coil

Lanzar MAX15D 15" Pro Woofer DVC 4 Ohms per Coil

Lanzar
Part #267-486

Lanzar MAX15D 15" Pro Woofer DVC 4 Ohms per Coil

Lanzar
Part #267-486
Model: MAX8
The Lanzar MAX15D 15" Pro Woofer DVC is a high-performance subwoofer designed to deliver deep, powerful bass for car audio enthusiasts. With a dual voice coil configuration and robust construction, this woofer provides flexibility in wiring options and ensures exceptional low-frequency sound for a rich, dynamic audio experience.
Key Features
  • Dual voice coil (DVC) design allows flexible wiring optionality
  • 2,000-watt peak power capacity for dynamic and high-impact sound output
  • Stamped plastic basket and treated foam surround ensure durability and enhanced sound quality
  • 2.5-inch high-temperature voice coil for extended, distortion-free operation
Similar items that may interest you:
See all items in Car Subwoofer Speakers
Your Price: $99.98
+ FREE SHIPPING
Bulk Pricing
Ships next business day. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Lanzar MAX15D 15" Pro Woofer DVC 4 Ohms per Coil

Unleash the full potential of your car audio system with the Lanzar MAX15D 15" Pro Woofer, engineered to deliver thunderous bass and a rich, dynamic sound experience. With a massive 2,000 watt peak power capacity, this woofer ensures deep, resonant low-end performance that fills your vehicle with powerful bass. The dual voice coil design provides flexible wiring options, allowing you to maximize power handling and tailor your setup to your needs. With a dual 4 ohm voice coil, your options are wide open to set up this woofer in a variety of different systems to meet your needs.

Built for durability and superior sound quality, the MAX15D features a stamped steel basket and a specially treated foam surround, enhancing both bass response and long-lasting performance. The non-pressed paper cone delivers clean, accurate bass, while the 2.5-inch high-temperature voice coil ensures distortion-free sound during extended use. Whether installed in a sealed or ported enclosure, the Lanzar MAX15D integrates seamlessly into any setup, making it the perfect addition to your car audio system for those seeking deep, heart-pounding bass.

Specifications:

  • Black Non-Pressed Paper Cone
  • Specially Treated Foam Edge Suspension
  • Stamped Plastic Basket w/Hex Key Input Terminal
  • Bumped Vented Motor Structure
  • Custom Designed Rubber Magnet Boot
  • 2.5'' Dual Layer High Temperature Kapton Voice Coil
  • 100 + 100 oz. Heavy Double Stacked Magnet Structure
  • 2000 Watts Peak Power
  • Mounting Depth:7.64"
  • Dual 4 Ohms Nom. Impedance
  • Fs: 30Hz
  • Qms: 5.0
  • Qes: 0.90
  • Qts: 0.75
  • SPL: 89(dB)
  • Vas: 6.02(Cuft)

Product Details

BrandLanzar
ModelMAX8
Part Number267-486
UPC068888710794
Unit of MeasureEach
Weight16

Product Specifications

Nominal Diameter15"
Power Handling (RMS)600 Watts
Power Handling (MAX)1200 Watts
Impedance4Ω
Sensitivity90.3dB 2.83V/1m
Voice Coil Diameter2.5"

Materials of Construction

Cone MaterialPaper
Surround MaterialRubber
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialSteel

Mounting Information

Overall Outside Diameter15.12"
Depth7.68"
# Mounting Holes8
