LaVoce SSF082.00L 8" Paper Cone Subwoofer

1 Question, 2 Answers or
Lavoce
Part #293-784

LaVoce SSF082.00L 8" Paper Cone Subwoofer

Lavoce
Part #293-784
Model: SSF082.00L
1 Question, 2 Answers or
The Lavoce SSF082.00L is the perfect candidate for a high-powered woofer or subwoofer application. Boasting 350 watts of RMS power, 29mm P-P maximum excursion and a 2” diameter CCAW voice coil, this woofer is ideal for chest thumping bass for home, studio or small PA applications.

Key Features
  • 2” copper clad aluminum voice coil for exceptional power handling
  • 700 watt program power handling (350WRMS)
  • Long throw design, 29mm (1.1”) P-P excursion
  • FEM optimized motor and suspensions
  • Long lasting rubber surround
  • Heavy duty treated paper cone
Your Price: $99.00
MSRP: $147.76
Save $48.76 (33%)
Bulk Pricing
Order in the next 5 hr 1 min to ship today. Details

Only 2 In Stock

More due any day
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

LaVoce SSF082.00L 8" Paper Cone Subwoofer

The Lavoce SSF082.00L is the perfect candidate for a high-powered woofer or subwoofer application. Boasting 350 watts of RMS power, 29mm P-P maximum excursion and a 2” diameter CCAW voice coil, this woofer is ideal for chest thumping bass in home, studio or small PA applications. This woofer can be front or rear mounted and uses a heavy duty resonance-free steel basket design and optimized cooling for long lasting durability. With a sensitivity of 88 dB, it won’t require the biggest amplifiers to drive efficiently.


Product Details

BrandLavoce
ModelSSF082.00L
Part Number293-784
UPC848864069715
Unit of MeasureEach
Weight10.5

Product Specifications

Nominal Diameter8"
Power Handling (RMS)350 Watts
Power Handling (MAX)700 Watts
Impedance8Ω
Frequency Response50 to 500Hz
Sensitivity88dB 2.83V/1m
Voice Coil Diameter2"

Thiele-Small Parameters

Resonant Frequency (Fs)52Hz
DC Resistance (Re)5.2Ω
Voice Coil Inductance (Le)2.51mH
Mechanical Q (Qms)9.94
Electromagnetic Q (Qes)0.52
Total Q (Qts)0.49
Compliance Equivalent Volume (Vas)0.34ft³
Mechanical Compliance of Suspension (Cms)0.144mm/N
BL Product (BL)14.67T·m
Diaphragm Mass Inc. Airload (Mms)66.3g
Maximum Linear Excursion (Xmax)9mm
Surface Area of Cone (Sd)216.42cm²

Materials of Construction

Cone MaterialPaper-Treated Paper
Surround MaterialRubber
Voice Coil Wire MaterialCCA
Voice Coil FormerFiberglass
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter8.27"
Baffle Cutout Diameter7.17"
Depth4.49"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.35ft³
Sealed F360.2Hz
Vented Volume0.7ft³
Vented F342.5Hz
