LaVoce FSN030.71 3" Neodymium Full-Range Woofer 8 Ohm

LavocePart # 293-706
Model: FSN030.71
1 Question, 1 Answer or
The LaVoce FSN030.71 is an impressive 3" full-range that features a rising response and compact frame, ideal for line arrays.

Key Features

  • FEM optimized Neodymium motor
  • Copper shorting sleeve for extended frequency response
  • Durable steel frame designed to reduce resonance
  • Integrated gasket allows for proper rear mounting
Your Price: $33.00
MSRP: $49.00
Save $16.00 (33%)
Bulk Pricing
5 In Stock
Get Notified When Available

We'll send you an email when LaVoce FSN030.71 3" Neodymium Full-Range Woofer 8 Ohm is back in stock or available for preorder.

Ships next business day. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

LaVoce FSN030.71 3" Neodymium Full-Range Woofer 8 Ohm

The LaVoce FSN030.71 is an impressive 3" full-range driver that offers a waterproof treated paper cone. The rising response and the compact frame offered by this driver is ideal for line arrays and compact audio installations. The gasket on the front of the driver allows for it to be properly rear mounted.

Product Details

BrandLavoce
ModelFSN030.71
Part Number293-706
UPC848864057286
Unit of MeasureEach
Weight0.55

Product Specifications

Nominal Diameter3"
Bolt Circle Diameter3.23
Power Handling (RMS)30 Watts
Power Handling (MAX)60 Watts
Impedance8Ω
Frequency Response120 to 21,000Hz
Sensitivity89dB 2.83V/1m
Voice Coil Diameter0.75"

Thiele-Small Parameters

Resonant Frequency (Fs)130Hz
DC Resistance (Re)6.4Ω
Voice Coil Inductance (Le)0.07mH
Mechanical Q (Qms)4.3
Electromagnetic Q (Qes)0.65
Total Q (Qts)0.56
Compliance Equivalent Volume (Vas)0.04ft³
Mechanical Compliance of Suspension (Cms)0.79mm/N
BL Product (BL)3.9T·m
Diaphragm Mass Inc. Airload (Mms)1.8g
Maximum Linear Excursion (Xmax)2.1mm
Surface Area of Cone (Sd)33.2cm²

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialRubber
Voice Coil Wire MaterialCCA
Voice Coil FormerFiberglass
Basket / Frame MaterialSteel
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter3.31"
Baffle Cutout Diameter2.77"
Depth1.77"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.04ft³
Sealed F3184.3Hz
Vented Volume0.08ft³
Vented F3101.2Hz
