HiVi T20-8 3/4" (20mm) Textile Dome Tweeter 8 Ohm

HiViPart # 297-464
Model: T20-8
The ultra-compact T20-8 from HiVi is an excellent choice for smaller designs such as portable systems, sound bars, and bookshelf speakers. The powerful neodymium motor allows this tweeter to have a faceplate or only 2" diameter while keeping sensitivity up to 89 dB.

Key Features

  • Only 2" diameter to fit into the tightest locations
  • Extremely smooth response from 4,000 to over 20,000 Hz
  • Powerful neodymium motor keeps depth under 1/2"
  • 3/4" soft dome delivers smooth response with minimal resonances
Your Price: $9.29
MSRP: $11.99
Save $2.70 (23%)
Bulk Pricing
Quantity:Qty: 1-3 $9.29/ea
Quantity:Qty: 4-9 $8.88/ea
Quantity:Qty: 10+ $8.46/ea
In Stock
Get Notified When Available

We'll send you an email when HiVi T20-8 3/4" (20mm) Textile Dome Tweeter 8 Ohm is back in stock or available for preorder.

Ships next business day. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

HiVi T20-8 3/4" (20mm) Textile Dome Tweeter 8 Ohm

HiVi's T20-8 3/4" soft dome tweeter provides smooth response and good efficiency from an extremely compact design. Thanks to the powerful neodymium motor, the T20-8 is only 2" diameter and 1/2" deep allowing it to fit almost anywhere. The 3/4" soft dome diaphragm produces smooth response from 4,000 to 20,000 Hz with minimal resonances for a natural sound. For added convenience, the included gasket makes it easy to install the T20-8 with an air tight seal.

Product Details

BrandHiVi
ModelT20-8
Part Number297-464
UPC848864051901
Unit of MeasureEach
Weight0.1

Product Specifications

Cone / Dome Diameter0.75"
Cutout Diameter1.385
Tweeter TypeSoft Dome
Power Handling (RMS)15 Watts
Impedance
Frequency Response4,000 to 20,000Hz
Sensitivity89dB 2.83V/1m

Thiele-Small Parameters

Resonant Frequency (Fs)2000Hz
DC Resistance (Re)6.5Ω
Voice Coil Inductance (Le)0.05mH

Mounting Information

Overall Outside Diameter2"
Depth0.5"
