NEW HiVi Q2R 1-1/8" Textile Dome Tweeter

HiViPart # 297-418
Model: Q2R
1 Question, 1 Answer or

A precisely manufactured German diaphragm is mated to a large, shielded motor structure. The result is a tweeter with excellent timbre and low distortion characteristics.

Key Features

  • Extremely flat response of 1,500-20,000 Hz
  • 1-1/8" soft dome delivers natural response with great dispersion
  • Double rear chamber design lowers Fs and improves damping
  • Popular replacement tweeter for the classic AR3a speaker system
NEW $22.98
MSRP: $28.99
Save $6.01 (21%)
Bulk Pricing
Quantity:Qty: 1-3 $22.98/ea
Quantity:Qty: 4-9 $21.98/ea
Quantity:Qty: 10+ $20.98/ea
Back-Ordered
Get Notified When Available

We'll send you an email when HiVi Q2R 1-1/8" Textile Dome Tweeter is back in stock or available for preorder.

Estimated back in stock 11/1/2025
Alert Me When Available
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

HiVi Q2R 1-1/8" Textile Dome Tweeter

HiVi Q2R 1-1/8" Textile Dome Tweeter

    This design features a 28mm German soft dome diaphragm with a specialized damping layer treatment, delivering a wide and linear frequency response for clearer and more transparent sound. The high-performance ferrite magnetic circuit ensures a uniform and stable magnetic field, effectively reducing harmonic distortion. Utilizing advanced American liquid magnetic cooling technology, a high-temperature resistant aluminum alloy frame, and a copper-clad aluminum wire voice coil, this tweeter offers enhanced power handling and durability. Staying true to HiVi's Hi-end audio philosophy, it produces a natural and well-rounded sound with refined transient response, rich detail, and exceptional clarity without harshness. Ideal for home Hi-Fi applications, this unit provides a high-fidelity listening experience with precision and depth.

  • Rated Impedance: 6Ω
  • Resonant Frequency: 1000Hz
  • Rated Power: 15W
  • Maximum Power: 30W
  • Sensitivity (2.83v/1m): 90 dB
  • Weight: 0.8kg
  • Voice Coil Diameter: 28mm
  • DC Resistance: 5.1Ω
  • Voice Coil Former: High Temperature Aluminum
  • Magnetic Circuit Type: External Magnetic Circuit
  • Magnet Material: High Performance Ferrite
  • Recommended Frequency: >2500Hz

Product Details

BrandHiVi
ModelQ2R
Part Number297-418
UPC848864079271
Unit of MeasureEach
Weight1

Product Specifications

Power Handling (RMS)15 Watts
Impedance6Ω
Frequency Response1500-20000Hz
Sensitivity90dB 2.83V/1m

Thiele-Small Parameters

Resonant Frequency (Fs)1000Hz
DC Resistance (Re)5.1Ω

Mounting Information

Depth0.35"
