  • HiVi E8 8" Treated Paper Cone Woofer

HiVi E8 8" Treated Paper Cone Woofer

HiViPart # 297-480
Model: E8
The HiVi E8 is an all around excellent choice for a powerful and clean mid-woofer in a wide range of applications.

Key Features

  • Ultra-light natural fiber cone for natural tone
  • Natural rubber surround for clean excursion
  • Strong aluminum frame for long lasting durability
  • Large motor and low 0.32 Qts for increased sensitivity
Your Price: $112.98
+ FREE SHIPPING
MSRP: $162.99
Save $50.01 (31%)
Bulk Pricing
Quantity:Qty: 1-3 $112.98/ea
Quantity:Qty: 4-9 $107.98/ea
Quantity:Qty: 10+ $102.98/ea
In Stock
Get Notified When Available

We'll send you an email when HiVi E8 8" Treated Paper Cone Woofer is back in stock or available for preorder.

Ships next business day. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

HiVi E8 8" Treated Paper Cone Woofer

The HiVi E8 is a well engineered, high quality mid-bass that will work well in numerous applications. The black natural fiber cone is lightweight and stiff, but well damped for extended useable frequency response. A large ferrite motor and a Qt of 0.32 means this will work optimally in smaller ported enclosures. The aluminum voice coil former increases power handling and the cast frame will make this a durable woofer for years.

Product Details

BrandHiVi
ModelE8
Part Number297-480
UPC848864070605
Unit of MeasureEach
Weight6

Product Specifications

Nominal Diameter8"
Power Handling (RMS)80 Watts
Power Handling (MAX)160 Watts
Impedance8Ω
Sensitivity89dB 2.83V/1m
Voice Coil Diameter1.38"

Thiele-Small Parameters

Resonant Frequency (Fs)34Hz
DC Resistance (Re)7.2Ω
Mechanical Q (Qms)2.84
Electromagnetic Q (Qes)0.43
Total Q (Qts)0.37
Compliance Equivalent Volume (Vas)1.76ft³
BL Product (BL)9.9T·m
Diaphragm Mass Inc. Airload (Mms)28.5g
Maximum Linear Excursion (Xmax)5.9mm

Materials of Construction

Cone MaterialTreated Paper
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter8.46"
Baffle Cutout Diameter7.36"
Depth3.46"
# Mounting Holes6

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.45ft³
Sealed F372.3Hz
Vented Volume1.25ft³
Vented F338.5Hz
