BUYOUT HSU Research VTF-2 10" Woofer

Factory Buyouts
Part #299-4044

BUYOUT HSU Research VTF-2 10" Woofer

Factory Buyouts
Part #299-4044
Model: VTF-2 (PF1030RPV)
The HSU Research VTF-2 is an impressive 10" subwoofer that excels in accurate bass reproduction. Due to the fact that this driver requires a relatively small enclosure, this driver would be a great fit for compact home audio setups or a car audio system.
Key Features
  • Bucking magnet for focused magnetic field
  • Strong, progressive roll poly-cotton spider that has 10 times the life of standard cotton spiders
  • Flange gasket for easy rear mounting
  • Extremely compliant foam surround
60 Day No Hassle Return Policy

Overview

HSU Research VTF-2 10" Woofer

HSU Research is known in the Hi-Fi world as one of the premier subwoofer manufacturers in the industry. HSU Research began as a specialized deep bass research company in 1991. Dr. Hsu started the business shortly after receiving a PhD in engineering from MIT. He moved to Orange County, California with the dream of making the world’s best subwoofers.

The VTF-2 is a rugged 10" subwoofer that works performs well in small to medium sized sealed enclosures. The Xmax of the VTF-2 is measured at 8 mm which is more than adequate for this wonderfully accurate driver. Add to that quick transients, and you have a subwoofer geared towards sound quality as well as impressive output.

Product Details

BrandFactory Buyouts
ModelVTF-2 (PF1030RPV)
Part Number299-4044
UPC848864058672
Unit of MeasureEach
Weight8.15

Product Specifications

Nominal Diameter10"
Power Handling (RMS)200 Watts
Impedance4Ω
Frequency Response35 to 500Hz
Sensitivity88.44dB 2.83V/1m
Voice Coil Diameter1.5"

Thiele-Small Parameters

Resonant Frequency (Fs)38.36Hz
DC Resistance (Re)3.202Ω
Voice Coil Inductance (Le)1.114mH
Mechanical Q (Qms)7.15
Electromagnetic Q (Qes)0.48
Total Q (Qts)0.45
Compliance Equivalent Volume (Vas)1.36ft³
Mechanical Compliance of Suspension (Cms)0.208mm/N
BL Product (BL)11.53T·m
Diaphragm Mass Inc. Airload (Mms)82.85g
Maximum Linear Excursion (Xmax)8mm
Surface Area of Cone (Sd)394.1cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialFoam
Voice Coil Wire MaterialCopper
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter10.06"
Baffle Cutout Diameter9.06"
Depth5"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.294ft³
Sealed F382.83Hz
Vented Volume1.307ft³
Vented F337.68Hz
