  • Goldwood GT-1188 Piezo Horn Driver 1-3/8"-18 TPI

CLEARANCE Goldwood GT-1188 Piezo Horn Driver 1-3/8"-18 TPI

GoldwoodPart # 270-082
Model: GT-1188
Goldwood's GT-1188 high power piezo driver is an excellent replacement for the popular Motorola/CTS KSN1188A. This 60 watt RMS driver incorporates protective circuitry which allows it to handle 400 watts of continuous power.

Key Features

  • Makes an excellent low priced upper midrange/tweeter driver
  • 1-3/8" 18 TPI mount for easy connection to many popular horns
  • Piezo drivers do not require a crossover and are an easy load for most amps
  • Extremely fast transient response
  • Internal protection circuitry handles up to 400 watts of continuous power
Similar items that may interest you:
GRS PZ1188 Piezo Horn Driver Similar to KSN1188A
Price: $5.79Part # 292-450
See all items in Horn Drivers
Get Notified When Available

We'll send you an email when Goldwood GT-1188 Piezo Horn Driver 1-3/8"-18 TPI is back in stock or available for preorder.

60 Day No Hassle Return Policy

Overview

Goldwood GT-1188 Piezo Horn Driver 1-3/8"-18 TPI

Built in transformer circuit for increased output and power handling. Similar to KSN1188A.

Specifications: • Power handling: 60 watts RMS, 120 watts (internal protection circuitry dissipates up to 400 watts) • Frequency response: 800 to 30,000 Hz • SPL: 93 dB 1W/1m • Mounts to any 1-3/8"-18 TPI horn • Dimensions: Overall diameter: 4", Depth: 2-1/2".

Product Details

BrandGoldwood
ModelGT-1188
Part Number270-082
UPC844632040979
Unit of MeasureEach
Weight0.7568

Product Specifications

Diaphragm MaterialPiezo Ceramic
Exit Diameter1"
Mounting Type1-3/8"-18 TPI
Power Handling (RMS)200 Watts
