GRS 5SBM-8 5" Sealed Back Midrange

GRS
Part #292-432

GRS 5SBM-8 5" Sealed Back Midrange

GRS
Part #292-432
Model: 5SBM-8
The GRS 5SBM-8 5" sealed back midrange speaker is a perfect replacement for many popular 3-way and 4-way loudspeaker systems produced during the last couple of decades.
Key Features
  • Fully enclosed steel chassis does not require a separate enclosure
  • Paper cone with paper surround for efficiency and extended range
  • 12 oz. ferrite magnet provides superior motor strength and high power handling capacity
  • Integral metal screen protects moving parts
Your Price: $6.98
MSRP: $9.99
Save $3.01 (30%)
Bulk Pricing
Quantity:Qty: 1-3 $6.98/ea
Quantity:Qty: 4+$6.28/ea
Ships next business day. Details

295In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

GRS 5SBM-8 5" Sealed Back Midrange

The GRS 5SBM-8 5" sealed back midrange speaker is a perfect replacement for many popular 3-way and 4-way loudspeaker systems produced during the last couple of decades. The driver's enclosed chassis eliminates the need to provide a separate sub-enclosure; the 5SBM-8 is a drop-in alternative driver for many applications, as well as providing excellent performance in new projects, too.

Product Details

BrandGRS
Model5SBM-8
Part Number292-432
UPC844632091230
Unit of MeasureEach
Weight1.75

Product Specifications

Nominal Diameter5"
Power Handling (RMS)30 Watts
Power Handling (MAX)60 Watts
Impedance8Ω
Frequency Response600 to 10,000Hz
Sensitivity90dB 2.83V/1m
Voice Coil Diameter0.75"

Thiele-Small Parameters

Resonant Frequency (Fs)467Hz
DC Resistance (Re)7.4Ω
Voice Coil Inductance (Le)0.6mH

Materials of Construction

Cone MaterialPaper
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter5.13"
Baffle Cutout Diameter4.13"
Depth2.25"
# Mounting Holes4
