GRS 1TD2-8 1" Designer Dome Tweeter 8 Ohm

GRS
Part #292-464

GRS 1TD2-8 1" Designer Dome Tweeter 8 Ohm

GRS
Part #292-464
Model: 1TD2-8
The GRS 1TD2-8 designer dome tweeter is an economical replacement for dome tweeters in classic speakers. Its stylized faceplate also makes it a great-looking addition to new builds.
Key Features
  • Fabric dome with 1" voice coil
  • Round injection-molded faceplate
  • Smooth, detailed sound quality
  • Great-looking replacement for classic dome tweeters
Your Price: $7.98
MSRP: $12.99
Save $5.01 (39%)
Bulk Pricing
Order in the next 2 hr 59 min to ship today. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

GRS 1TD2-8 1" Designer Dome Tweeter 8 Ohm

When you need an economical replacement dome tweeter, but you want to preserve or create an elegant look, make the GRS 1TD2-8 your choice. Its European-styled faceplate makes it the perfect replacement for more expensive dome tweeters, but it’s also great for new designs.

The round 4" faceplate is perfectly sized to fit existing tweeter cutouts, and the shape of the faceplate is curved to reduce edge diffraction for smooth frequency response and great detail. The large ferrite motor provides dynamic output, while the 1" voice coil handles plenty of power. The 8-ohm impedance allows it to work great with most existing crossovers.

Product Details

BrandGRS
Model1TD2-8
Part Number292-464
UPC848864016399
Unit of MeasureEach
Weight1.15

Product Specifications

Cone / Dome Diameter1"
Cutout Diameter2.875
Tweeter TypeSoft Dome
Power Handling (RMS)50 Watts
Impedance8Ω
Frequency Response2,100 to 20,000Hz
Sensitivity90dB 2.83V/1m

Thiele-Small Parameters

Resonant Frequency (Fs)2531Hz
DC Resistance (Re)7.32Ω
Voice Coil Inductance (Le)0.25mH
Mechanical Q (Qms)5.94
Electromagnetic Q (Qes)1.91
Total Q (Qts)1.45

Mounting Information

Overall Outside Diameter4.06"
Depth1.25"
