CLEARANCE Fountek FR58EX 2" Neodymium Full Range Speaker Driver

Fountek
Part #296-725

CLEARANCE Fountek FR58EX 2" Neodymium Full Range Speaker Driver

Fountek
Part #296-725
Model: FR58EX
Fountek’s FR58EX is a premium 2" small full-range driver that features an attractive thin-foil aluminum cone, steel frame, and an optimized high-strength neodymium motor, for low distortion and excellent detail.
Key Features
  • Ultra-linear frequency response from 150 to 20,000 Hz
  • Gorgeous aluminum cone
  • Neodymium motor with 2.9 mm of Xmax
  • Extremely fast transient response for clear, accurate high end
60 Day No Hassle Return Policy

Overview

Fountek FR58EX 2" Neodymium Full Range Speaker Driver

Fountek has applied much of what it has learned from designing industry-leading ribbon transducers in creating its line of full-range drivers. These high-performing cone drivers feature thin-foil aluminum diaphragms that shed resonance rapidly, for exceptional detail and smooth frequency response.

The 2" FR58EX model is the smallest, and features a high-strength neodymium motor structure for low distortion, extended excursion, and excellent transient response. It’s a great choice for desktop multimedia speakers, micro-satellite speakers, or line arrays.

Product Details

BrandFountek
ModelFR58EX
Part Number296-725
UPC848864004211
Unit of MeasureEach
Weight0.4

Product Specifications

Nominal Diameter2"
Bolt Circle Diameter2.6
Power Handling (RMS)15 Watts
Power Handling (MAX)30 Watts
Impedance8Ω
Frequency Response130 to 20,000Hz
Sensitivity82.3dB 2.83V/1m
Voice Coil Diameter0.79"

Thiele-Small Parameters

Resonant Frequency (Fs)134Hz
DC Resistance (Re)6.4Ω
Mechanical Q (Qms)2.6
Electromagnetic Q (Qes)0.69
Total Q (Qts)0.55
Compliance Equivalent Volume (Vas)0.01ft³
BL Product (BL)3.39T·m
Maximum Linear Excursion (Xmax)2.9mm
Surface Area of Cone (Sd)17.35cm²

Materials of Construction

Cone MaterialAluminum
Surround MaterialPolyurethane
Voice Coil Wire MaterialCopper
Voice Coil FormerAluminum
Basket / Frame MaterialSteel
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter2.44" x 2.44"
Baffle Cutout Diameter2.02"
Depth1.3"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.01ft³
Sealed F3196Hz
Vented Volume0.02ft³
Vented F395Hz
