FaitalPRO 6RS140 6" Professional Neodymium Midbass 8 Ohm

FaitalPROPart # 294-1321
Model: 6RS140
3 Questions, 3 Answers or
Built to deliver high output with low distortion, Faital Pro's 6RS140 6" professional midrange driver uses a naturally damped paper cone to produce natural response up to 6,000 Hz, even at 45 degrees off-axis. Featuring a powerful neodymium magnet, aluminum shorting ring, rugged cast aluminum frame, and 1.75" voice coil, this midrange is ideal for use in 3-way high output speaker systems.

Key Features

  • FEA optimized neodymium motor for high efficiency with minimal weight
  • 1.75" voice coil with fiberglass former to handle up to 200 watts RMS
  • Capable of 5.6 mm of excursion for high impact midbass output
  • Large aluminum shorting ring keeps inductance and distortion extremely low
Your Price: $198.00
+ FREE SHIPPING
Bulk Pricing
Only 2 In Stock
Get Notified When Available

We'll send you an email when FaitalPRO 6RS140 6" Professional Neodymium Midbass 8 Ohm is back in stock or available for preorder.

Order in the next 1 hr 35 min to ship today. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

FaitalPRO 6RS140 6" Professional Neodymium Midbass 8 Ohm

Faital Pro's 6RS140 6" professional midrange driver is capable of delivering high output midrange and midbass response with extremely low distortion. This driver uses a high energy neodymium motor assembly to deliver excellent efficiency and excursion capability while keeping weight to a minimum. The motor assembly also includes an aluminum demodulation ring to lower inductance which extends the high frequency response and reduces distortion. A naturally damped curvilinear paper cone produces smooth response from 60 to 6,000 Hz, even up to 45 degrees off axis. With a 1.75" voice coil wound on a heat resistant fiberglass former, the 6RS140 can handle 200 watts RMS for incredible overall output capability. All of this makes Faital Pro's 6RS140 ideal for use in anything from high output studio monitors to extreme SPL mobile sound systems.

Product Details

BrandFaitalPRO
Model6RS140
Part Number294-1321
UPC848864063119
Unit of MeasureEach
Weight2.65

Product Specifications

Nominal Diameter6"
Bolt Circle Diameter6.77
Power Handling (RMS)200 Watts
Power Handling (MAX)400 Watts
Impedance8Ω
Frequency Response60 to 6,000Hz
Sensitivity93dB 2.83V/1m
Voice Coil Diameter1.73"

Thiele-Small Parameters

Resonant Frequency (Fs)65Hz
DC Resistance (Re)5.3Ω
Voice Coil Inductance (Le)0.28mH
Mechanical Q (Qms)5.8
Electromagnetic Q (Qes)0.28
Total Q (Qts)0.27
Compliance Equivalent Volume (Vas)0.28ft³
Mechanical Compliance of Suspension (Cms)0.37mm/N
BL Product (BL)11T·m
Diaphragm Mass Inc. Airload (Mms)16g
Maximum Linear Excursion (Xmax)5.6mm
Surface Area of Cone (Sd)122.6cm²

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialCloth
Voice Coil Wire MaterialAluminum
Basket / Frame MaterialCast Aluminum
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter6.37"
Baffle Cutout Diameter5.79"
Depth2.99"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Vented Volume0.3ft³
Vented F367.3Hz
