  • FaitalPRO 18FH500 18" Neodymium Professional Subwoofer 8 Ohm

FaitalPRO 18FH500 18" Neodymium Professional Subwoofer 8 Ohm

FaitalPROPart # 294-1300
Model: 18FH500
For a lightweight, high output subwoofer solution, choose FaitalPRO's neodymium-powered 18FH500 18" subwoofer.

Key Features

  • Custom cast aluminum frame
  • Rare earth neodymium slug motor
  • Triple roll treated polycotton surround
  • Designed for vented and horn loaded enclosures
  • Made in Italy
Your Price: $480.00
+ FREE SHIPPING
Bulk Pricing
5 In Stock
Get Notified When Available

We'll send you an email when FaitalPRO 18FH500 18" Neodymium Professional Subwoofer 8 Ohm is back in stock or available for preorder.

Order in the next 13 hr 3 min to ship today. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

FaitalPRO 18FH500 18" Neodymium Professional Subwoofer 8 Ohm

FaitalPRO's Five Hundred Series drivers are built to be highly reliable and versatile. An extended frequency response that reaches to 3,000 Hz allows this 18" to be used in large multi-way speakers as a woofer.

A cast aluminum eight-spoke frame reduces rear reflections and increases basket strength, while the triple roll treated polycotton surround maintains linearity during heavy excursion. The high power neodymium motor keeps sensitivity high while decreasing the weight of the driver. Made in Italy.

Product Details

BrandFaitalPRO
Model18FH500
Part Number294-1300
UPC848864008134
Unit of MeasureEach
Weight13.75

Product Specifications

Nominal Diameter18"
Bolt Circle Diameter17.32
Power Handling (RMS)600 Watts
Power Handling (MAX)1200 Watts
Impedance8Ω
Frequency Response30 to 3,150Hz
Sensitivity99dB 2.83V/1m
Voice Coil Diameter3"

Thiele-Small Parameters

Resonant Frequency (Fs)30Hz
DC Resistance (Re)5.1Ω
Voice Coil Inductance (Le)1.35mH
Mechanical Q (Qms)12.5
Electromagnetic Q (Qes)0.36
Total Q (Qts)0.35
Compliance Equivalent Volume (Vas)12.23ft³
Mechanical Compliance of Suspension (Cms)0.21mm/N
BL Product (BL)19T·m
Diaphragm Mass Inc. Airload (Mms)137g
Maximum Linear Excursion (Xmax)9.25mm
Surface Area of Cone (Sd)1134cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialCloth
Voice Coil Wire MaterialCopper
Voice Coil FormerFiberglass
Basket / Frame MaterialCast Aluminum
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter18.11"
Baffle Cutout Diameter16.61"
Depth7.95"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume3ft³
Sealed F368.4Hz
Vented Volume6.5ft³
Vented F341Hz
