FaitalPRO 15PR400 15" Neodymium Professional Woofer 8 Ohm

FaitalPROPart # 294-1271
Model: 15PR400
Choose FaitalPRO's 15" 15PR400 woofer to replace or upgrade the woofer in your speaker cabinet. A flat frequency response to 4,000 Hz and high sensitivity of 99 dB (1W/1m) allows it to match well with nearly any horn driver.

Key Features

  • Lightweight design weighs just under 8 pounds
  • 99 dB sensitivity due to high-energy neo motor
  • Durable cast-aluminum frame
  • Ultra-linear frequency response
  • Made in Italy
Your Price: $373.00
+ FREE SHIPPING
Bulk Pricing
5 In Stock
Get Notified When Available

We'll send you an email when FaitalPRO 15PR400 15" Neodymium Professional Woofer 8 Ohm is back in stock or available for preorder.

Ships next business day. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

FaitalPRO 15PR400 15" Neodymium Professional Woofer 8 Ohm

With high sensitivity and a ruler-flat frequency response from 35 Hz to 4,000 Hz, FaitalPRO's 15PR400 15" woofer is perfect for replacing and upgrading tired, worn-out woofers in small to large-sized, vented two-way speakers. The 15PR400 is a great choice for live sound and high output home audio speakers.

An eight-spoke, cast-aluminum frame adds structural integrity, while the treated paper cone and accordion cloth surround can withstand years of constant use. The 400 watt RMS power handling rating is made possible by the use of a 3" voice coil on a glass fiber former. A neodymium slug motor keeps weight low, just under 8 pounds. Made in Italy.

Product Details

BrandFaitalPRO
Model15PR400
Part Number294-1271
UPC848864008301
Unit of MeasureEach
Weight10.85

Product Specifications

Nominal Diameter15"
Bolt Circle Diameter14.72
Power Handling (RMS)400 Watts
Power Handling (MAX)800 Watts
Impedance8Ω
Frequency Response35 to 4,000Hz
Sensitivity99dB 2.83V/1m
Voice Coil Diameter3"

Thiele-Small Parameters

Resonant Frequency (Fs)35Hz
DC Resistance (Re)5.1Ω
Voice Coil Inductance (Le)0.75mH
Mechanical Q (Qms)6.02
Electromagnetic Q (Qes)0.34
Total Q (Qts)0.32
Compliance Equivalent Volume (Vas)7.88ft³
Mechanical Compliance of Suspension (Cms)0.24mm/N
BL Product (BL)16.7T·m
Diaphragm Mass Inc. Airload (Mms)85.2g
Maximum Linear Excursion (Xmax)5.75mm
Surface Area of Cone (Sd)805cm²

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialCloth
Voice Coil Wire MaterialAluminum
Voice Coil FormerFiberglass
Basket / Frame MaterialCast Aluminum
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter15.47"
Baffle Cutout Diameter13.94"
Depth6.5"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume1.75ft³
Sealed F386.7Hz
Vented Volume3.25ft³
Vented F343.3Hz
