  • Eminence PXB2:1K6 2-Way Speaker Crossover Board 1,600 Hz

Eminence PXB2:1K6 2-Way Speaker Crossover Board 1,600 Hz

Eminence Speaker
Part #290-634

Eminence PXB2:1K6 2-Way Speaker Crossover Board 1,600 Hz

Eminence Speaker
Part #290-634
Model: PXB2:1K6
Eminence PXB crossovers feature advanced circuit design to both preserve the crossover and your HF drivers.
Key Features
  • Crossover type: Two-way, board only
  • Crossover frequency: 1,600 Hz, 18 dB/octave HP, 12 dB/octave LP
  • Power handling: 400 watts RMS
Your Price: $79.99
MSRP: $99.99
Save $20.00 (20%)
Bulk Pricing

Back-Ordered

Estimated back in stock 5/16/2025
Alert Me When Available
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Eminence PXB2:1K6 2-Way Speaker Crossover Board 1,600 Hz

Eminence PXB board-only crossovers are a lower cost alternative to the "cabinet ready" models and are targeted specifically for custom cabinet projects as they do not include the terminal cup, input connectors or L-pad found on the "cabinet ready" models. They feature advanced circuit design to both preserve the crossover and your drivers. A benefit of the design is to form a voltage divider across the high frequency driver. The high-pass protection uses custom-built aerospace lamps. The tungsten filaments effectively track the program material, dynamically maintaining a safe maximum current level to the high frequency driver without introducing distortion. This circuitry provides smooth 3:1 analog compression during input overload conditions over 250 watts RMS. At full drive level approaching clipping, the electrical attenuation to the protected high frequency driver is -4.5 dB. In every way, Eminence pxb crossovers are a technically superior product. For use with 8 ohm drivers.

Product Details

BrandEminence Speaker
ModelPXB2:1K6
Part Number290-634
UPC876358001446
Unit of MeasureEach
Weight1

Product Specifications

ConfigurationAssembled Board Only
Crossover Type2-Way
