Eminence N320T-8 2" Neo Compression Driver 8 Ohm 4-Bolt

Eminence SpeakerPart # 290-5610
Model: N320T-8
The 2" exit N320T-8 sets a new standard in compression drivers from Eminence. Featuring D3 technology (Damped Diametric Drive) to deliver linear response while allowing a smooth crossover point.

Key Features

  • Powerful neodymium magnet keeps weight and size to a minimum
  • Copper shorting ring lowers distortion and voice coil inductance
  • Cooling fins and 3" voice coil ensure high power handling for extended periods
  • 550 Hz resonance frequency allows crossover points as low as 800 Hz
Your Price: $244.99
+ FREE SHIPPING
MSRP: $274.99
Save $30.00 (11%)
Bulk Pricing
Only 4 In Stock
Get Notified When Available

We'll send you an email when Eminence N320T-8 2" Neo Compression Driver 8 Ohm 4-Bolt is back in stock or available for preorder.

Ships next business day. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Eminence N320T-8 2" Neo Compression Driver 8 Ohm 4-Bolt

Eminence has set a new standard in compression driver performance with the introduction of the N320T-8 2" exit neodymium driver. Weighing in at a mere 5 lbs, this driver boasts a broad usable frequency range of 800 Hz to 20 kHz.

The 3" titanium diaphragm features a geodesic rib pattern for increased stiffness and break-up control. Supporting the diaphragm is a polymer surround with D3™ technology (Damped Diametric Drive) to provide a smooth, clean, and extended response while still allowing a crossover point as low as 800 (at 12 dB per octave). With a power rating of 100 watts (AES) and a sensitivity of 110 dB, the N320T-8 will perform well in high output 2-way sound reinforcement systems. This driver uses a standard 4 bolt mount.

Specifications: • Power handling: 100 watts with minimum crossover of 800 Hz at 12 dB per octave • Fs: 521 Hz • VCdia: 3" • Impedance: 8 ohms • Frequency response: 800-20,000 Hz • SPL: 110 dB 1W/1m • Dimensions: 5.72" diameter x 3.1" depth • Net weight: 5 lbs.

Product Details

BrandEminence Speaker
ModelN320T-8
Part Number290-5610
UPC876358002665
Unit of MeasureEach
Weight5.85

Product Specifications

Diaphragm MaterialTitanium
Exit Diameter2"
Mounting Type4-Bolt
Power Handling (RMS)100 Watts
Impedance8Ω
