  • Eminence Legend CA154 15" Bass Guitar Driver 300W 4 Ohm

Eminence Legend CA154 15" Bass Guitar Driver 300W 4 Ohm

Eminence SpeakerPart # 290-466
Model: Legend CA154
Pro sound 15" woofer for use in bass guitar cabinets or in PA loudspeaker systems. 4-ohm driver with high sensitivity.

Key Features

  • Stamped steel basket
  • Copper voice coil wound on a polyimide former
  • Vented pole piece
  • For bass guitar and PA applications
  • 4 ohm nominal impedance
Your Price: $174.99
+ FREE SHIPPING
MSRP: $209.99
Save $35.00 (17%)
Bulk Pricing
Only 3 In Stock
Get Notified When Available

We'll send you an email when Eminence Legend CA154 15" Bass Guitar Driver 300W 4 Ohm is back in stock or available for preorder.

Ships next business day. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Eminence Legend CA154 15" Bass Guitar Driver 300W 4 Ohm

Pro sound 15" woofer for use in bass guitar cabinets or in PA loudspeaker systems. 4-ohm driver with high sensitivity. Stamped steel basket, copper voice coil wound on a polyimide former, and vented pole piece. Suitable for 1.4 to 2.5 cu. ft. sealed enclosures or 1.6 to 6 cu. ft. vented.

Specifications: • Power handling: 300 watts RMS/600 watts max • VCdia: 2-1/2" • Le: 0.80 mH • Impedance: 4 ohms • Re: 2.92 ohms • Frequency range: 45-3,000 Hz • Magnet weight: 56 oz. • Fs: 51 Hz • Sensitivity: 96.9 dB 1W/1m • Vas: 3.82 cu. ft. • Qms: 4.94 • Qes: 0.54 • Qts: 0.49 • Xmax: 5 mm • Dimensions: Overall Diameter: 15.15", Cutout Diameter: 13.87", Depth: 6.25".

Product Details

BrandEminence Speaker
ModelLegend CA154
Part Number290-466
UPC876358001484
Unit of MeasureEach
Weight14

Product Specifications

Nominal Diameter15"
Power Handling (RMS)300 Watts
Impedance4Ω

Materials of Construction

Magnet MaterialCeramic Ferrite
