BUYOUT Panasonic EAS14PL327A6 6" Paper Cone Woofer 6 ohm

Factory BuyoutsPart # 299-4138
Model: EAS14PL327A6
The Panasonic EAS14PL327A6 6" paper cone woofer is ideal as a replacement woofer, or as the low-end in your next budget build.

Key Features

  • Shielded magnet assembly is suitable for use near sensitive electronics
  • The basket uses high-quality stamped steel for outstanding stability under extreme stress
  • The bumped back plate allows the high-temp voice coil to move even more, so you get deeper bass without distortion
BUYOUT $4.99
MSRP: $9.98
Save $4.99 (50%)
Bulk Pricing
Quantity:Qty: 1-11 $4.99/ea
Quantity:Qty: 12+ $2.50/ea
233 In Stock
Get Notified When Available

We'll send you an email when Panasonic EAS14PL327A6 6" Paper Cone Woofer 6 ohm is back in stock or available for preorder.

Ships next business day. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Panasonic EAS14PL327A6 6" Paper Cone Woofer 6 ohm

Sporting a paper cone and foam surround, the Panasonic EAS14PL327A6 6" woofer is a well-built, smooth sounding woofer that will work equally well in ported or sealed enclosures. A 1" diameter 4-layer copper voice coil handles ample power and a vented cone helps keep things cool under high power applications. A bucking magnet allows close use near older CRT screens or mechanical hard drives without negative effects.

Product Details

BrandFactory Buyouts
ModelEAS14PL327A6
Part Number299-4138
UPC848864072180
Unit of MeasureEach
Weight1.7

Product Specifications

Nominal Diameter6"
Bolt Circle Diameter5.5
Power Handling (RMS)40 Watts
Power Handling (MAX)80 Watts
Impedance6Ω
Frequency Response50-4,000Hz
Sensitivity85.72dB 2.83V/1m
Voice Coil Diameter1"

Thiele-Small Parameters

Resonant Frequency (Fs)53.06Hz
DC Resistance (Re)4.819Ω
Voice Coil Inductance (Le)1.316mH
Mechanical Q (Qms)8.686
Electromagnetic Q (Qes)0.5594
Total Q (Qts)0.5256
Compliance Equivalent Volume (Vas)0.3191ft³
Diaphragm Mass Inc. Airload (Mms)12.77g
Maximum Linear Excursion (Xmax)2mm
Surface Area of Cone (Sd)95.55cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialFoam
Voice Coil Wire MaterialCopper
Voice Coil FormerPaper
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter6.125"
Baffle Cutout Diameter4.75"
Depth3.25"
# Mounting Holes12
