  • EAS10P241JD3 4" Paper Cone Full-Range Speaker 4 Ohm

BUYOUT EAS10P241JD3 4" Paper Cone Full-Range Speaker 4 Ohm

Factory BuyoutsPart # 299-4254
Model: EAS10P241JD3

The EAS10P241JD3 4" Paper Cone Full-Range Speaker utilizes a paper cone and treated paper surround for excellent damping characteristics.

Key Features

  • Rear-mount design helps hide mounting hardware
  • Great replacement in vintage boomboxes and small stereos
  • Small mounting flange makes this a good contender for line arrays
BUYOUT $2.98
MSRP: $6.99
Save $4.01 (57%)
Bulk Pricing
Quantity:Qty: 1-9 $2.98/ea
Quantity:Qty: 10-19 $2.48/ea
Quantity:Qty: 20+ $1.98/ea
1550 In Stock
Get Notified When Available

We'll send you an email when EAS10P241JD3 4" Paper Cone Full-Range Speaker 4 Ohm is back in stock or available for preorder.

Ships next business day. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

EAS10P241JD3 4" Paper Cone Full-Range Speaker 4 Ohm

The EAS10P241JD3 4" Paper Cone Full-Range Speaker utilizes a paper cone and treated paper surround for excellent damping characteristics. A 1/2" diameter CCA voice coil and paper former combine to give this small speaker an SPL of over 89 dB, making it require a small amount of power to reach full output.

Product Details

BrandFactory Buyouts
ModelEAS10P241JD3
Part Number299-4254
UPC848864073729
Unit of MeasureEach
Weight0.4

Product Specifications

Nominal Diameter4"
Bolt Circle Diameter4.25
Power Handling (RMS)5 Watts
Power Handling (MAX)10 Watts
Impedance
Frequency Response125 to 10,000Hz
Sensitivity89.81dB 2.83V/1m
Voice Coil Diameter0.5"

Thiele-Small Parameters

Resonant Frequency (Fs)124Hz
DC Resistance (Re)3.587Ω
Mechanical Q (Qms)6.18
Electromagnetic Q (Qes)1.311
Total Q (Qts)1.081
Compliance Equivalent Volume (Vas)0.1503ft³
Diaphragm Mass Inc. Airload (Mms)1.591g
Maximum Linear Excursion (Xmax)0.625mm
Surface Area of Cone (Sd)54.11cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialPaper
Voice Coil Wire MaterialCCA
Voice Coil FormerPaper
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter4"
Baffle Cutout Diameter3.625"
Depth1.625"
# Mounting Holes4
