CLEARANCE Dayton Audio TIT400C-4 15'' Titanic Mk III Subwoofer 4 Ohm

15 Questions, 36 Answers or
Dayton Audio
Part #295-420

CLEARANCE Dayton Audio TIT400C-4 15'' Titanic Mk III Subwoofer 4 Ohm

Dayton Audio
Part #295-420
Model: TIT400C-4
15 Questions, 36 Answers or
To produce loud, hard hitting, deep bass in large home environments, you need to move a lot of air, and the Dayton Audio Titanic MKIII 15" subwoofer speaker will do just that!
Key Features
  • Sturdy die cast frame keeps everything in perfect alignment
  • Stacked ceramic ferrite magnets provide massive motor strength
  • Extended pole piece keeps more voice coil wire in the magnetic field
  • Large diameter voice coil and under-spider venting handle the power
  • Kevlar-reinforced cone and large rubber surround allow full excursion
  • Manufactured in the USA

Overview

Dayton Audio TIT400C-4 15'' Titanic Mk III Subwoofer 4 Ohm

Optimized for a variety of enclosures, the Dayton Audio Titanic MKIII 15" speaker is THE driver when you are looking to build the ultimate home theater subwoofer! The Titanic MkIII sub will hit hard with deep, loud bass. Thanks to its large surface area and long excursion, the 15" MKIII will sweep over 3 liters of air!



Product Details

BrandDayton Audio
ModelTIT400C-4
Part Number295-420
UPC844632000553
Unit of MeasureEach
Weight24.2

Product Specifications

Nominal Diameter15"
Power Handling (RMS)800 Watts
Power Handling (MAX)1600 Watts
Impedance4Ω
Frequency Response19 to 500Hz
Sensitivity88.7dB 2.83V/1m
Voice Coil Diameter2.5"

Thiele-Small Parameters

Resonant Frequency (Fs)24.2Hz
DC Resistance (Re)3.8Ω
Voice Coil Inductance (Le)3.11mH
Mechanical Q (Qms)6.75
Electromagnetic Q (Qes)0.52
Total Q (Qts)0.49
Compliance Equivalent Volume (Vas)5.46ft³
Mechanical Compliance of Suspension (Cms)0.17mm/N
BL Product (BL)16.8T·m
Maximum Linear Excursion (Xmax)20.5mm
Surface Area of Cone (Sd)804.2cm²

Materials of Construction

Cone MaterialPaper / Kevlar
Surround MaterialRubber
Voice Coil Wire MaterialCopper
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter15.5"
Baffle Cutout Diameter14"
Depth7.8"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume2.43ft³
Sealed F342Hz
Vented Volume5.28ft³
Vented F322Hz
