  • Dayton Audio DVC310-88 12" DVC Series Subwoofer

CLEARANCE Dayton Audio DVC310-88 12" DVC Series Subwoofer

Dayton AudioPart # 295-185
Model: DVC310-88
Dayton Audio's DVC310-88 DVC Series 12" subwoofer produces clean, deep bass when loaded in sealed, vented, bandpass, or even transmission line designs. The dual 8 ohm voice coils allow for use in a variety of home or auto applications.

Key Features

  • Designed for sealed, vented, bandpass, and transmission line speaker systems
  • Dual 8 ohm voice coils offer plenty of connection flexibility
  • Kevlar-impregnated paper cone terminated with a durable, thick foam surround
  • US-engineered and manufactured 12" subwoofer driver
Similar items that may interest you:
Dayton Audio RSS315HO-44 12" Reference Series HO DVC Subwoofer
Price: $249.98Part # 295-467
See all items in Subwoofer Drivers
Get Notified When Available

We'll send you an email when Dayton Audio DVC310-88 12" DVC Series Subwoofer is back in stock or available for preorder.

60 Day No Hassle Return Policy

Overview

Dayton Audio DVC310-88 12" DVC Series Subwoofer

These DVC subwoofers are the most versatile drivers in the Dayton Audio line up. They were engineered to provide very good performance in sealed, vented, bandpass or even transmission line designs. The dual 8 ohm voice coils allow for use in a variety of applications and wiring configurations. Each driver features a heavy gauge stamped steel frame, super stiff Kevlar impregnated paper cone, thick foam surround, flat progressive spider, vented pole piece, dual high power Kapton voice coils, heavy duty braided tinsel leads, and high-quality pushbutton terminals. Made in the U.S.A. 5 Year Limited Warranty.



Product Details

BrandDayton Audio
ModelDVC310-88
Part Number295-185
UPC844632000065
Unit of MeasureEach
Weight17.4

Product Specifications

Nominal Diameter12"
Power Handling (RMS)350 Watts
Power Handling (MAX)700 Watts
Impedance8Ω
Frequency Response20 to 450Hz
Sensitivity89.8dB 2.83V/1m
Voice Coil Diameter2"

Thiele-Small Parameters

Resonant Frequency (Fs)19.5Hz
DC Resistance (Re)2.5Ω
Voice Coil Inductance (Le)2.37mH
Mechanical Q (Qms)7.95
Electromagnetic Q (Qes)0.41
Total Q (Qts)0.39
Compliance Equivalent Volume (Vas)3.7ft³
Mechanical Compliance of Suspension (Cms)0.29mm/N
BL Product (BL)13T·m
Maximum Linear Excursion (Xmax)15.1mm
Surface Area of Cone (Sd)502.7cm²

Materials of Construction

Cone MaterialPaper / Kevlar
Surround MaterialFoam
Voice Coil Wire MaterialCopper
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter12.25"
Baffle Cutout Diameter11.05"
Depth5.61"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.91ft³
Sealed F351Hz
Vented Volume2.5ft³
Vented F329Hz
