  • Dayton Audio AMT Mini-8 Hi-Res Air Motion Transformer Tweeter 8 Ohm

Dayton Audio AMT Mini-8 Hi-Res Air Motion Transformer Tweeter 8 Ohm

Dayton AudioPart # 275-095
Model: AMT Mini-8
Introducing the AMT Mini-8 Air Motion Transformer tweeter from Dayton Audio—your key to unlocking incredible clarity, lightning-fast transient response, and exceptional musicality in any loudspeaker design. With its impressive frequency range extending up to 40,000 Hz, this tweeter is the ideal solution for high-resolution audio systems that demand precision and detail. Its compact housing allows for effortless integration into various setups, while cutting-edge AMT technology ensures robust output from this remarkably small driver. Integrate the AMT Mini-8 into your speaker designs and experience the difference.

Key Features

  • Advanced Air Motion Transformer design delivers smooth response up to 40,000 Hz
  • Folded Kapton ribbon diaphragm delivers clean, detailed, and highly dynamic output
  • Compact design and Hi-Res capability, ideal for use as a super tweeter
  • Powerful, lightweight neodymium magnet structure for low distortion and high efficiency
  • Sonically similar to the best metal ribbon and planar tweeters
  • Miniature design can be mounted virtually anywhere
Similar items that may interest you:
HiVi RT2C-A Planar Isodynamic Tweeter
Price: $108.98Part # 297-406
See all items in Planar / Ribbon Transducers
Your Price: $31.98
MSRP: $45.99
Save $14.01 (30%)
Bulk Pricing
Quantity:Qty: 1-3 $31.98/ea
Quantity:Qty: 4+ $29.22/ea
In Stock
Get Notified When Available

We'll send you an email when Dayton Audio AMT Mini-8 Hi-Res Air Motion Transformer Tweeter 8 Ohm is back in stock or available for preorder.

Order in the next 3 hr 13 min to ship today. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Dayton Audio AMT Mini-8 Hi-Res Air Motion Transformer Tweeter 8 Ohm

The Dayton Audio AMT Mini-8 model redefines compact speaker design with its powerful motor system and advanced Air Motion Transformer (AMT) element. Engineered for wide dispersion, this tweeter is an excellent alternative to traditional dome tweeters in both retrofit and new applications. Its compact size makes it an ideal choice for satellite speakers, and it can also be seamlessly integrated into the center of a mid-woofer, resulting in a full-bandwidth coaxial driver. Additionally, its versatility allows for various implementations, including line arrays. The AMT Mini-8 features a sealed rear chamber design that eliminates the need for a separate internal chamber in the loudspeaker enclosure, enhancing both efficiency and performance.

Using advanced transducer technology derived from the original Heil Air Motion Transformer, the Dayton Audio AMT Mini-8 delivers ultra-clean, detailed, and dynamic treble output that is necessary for true audio fidelity. The pleated ribbon diaphragm contributes to a large acoustic radiating area, all contained within a compact chassis, allowing for impressive output levels with surprising power handling.

One of the standout features of the AMT Mini-8 is its impressive frequency response, extending up to 40,000 Hz. This capability ensures that listeners experience not just clarity and detail in the audible range, but also the subtle nuances that elevate high-resolution audio playback. With these attributes, the AMT Mini-8 is not merely a component; it is an essential upgrade for audio systems aiming for the most accurate sound reproduction. This performance and flexibility make the Dayton Audio AMT Mini-8 a great choice for audio enthusiasts and professionals alike.

Product Details

BrandDayton Audio
ModelAMT Mini-8
Part Number275-095
UPC848791000652
Unit of MeasureEach
Weight0.1278

Product Specifications

Cutout Diameter1.59
Tweeter TypeAMT Air Motion Transformer
Power Handling (RMS)15 Watts
Impedance8Ω
Frequency Response3,500 to 40,000Hz
Sensitivity88dB 2.83V/1m

Thiele-Small Parameters

Resonant Frequency (Fs)3500Hz
DC Resistance (Re)7.92Ω
Mechanical Q (Qms)1.86
Total Q (Qts)1.84

Mounting Information

Overall Outside DiameterWith faceplate 2.25"
Depth0.91"
