DS18 EXL-X6.2D 6-1/2" Cast Frame DVC Subwoofer 2 Ohm

DS18Part # 294-8080
Model: EXL-X6.2D
DS18 built the EXL-X6.2D 6-1/2" cast frame DVC subwoofer to produce maximum bass from minimum space. This compact high excursion driver is capable of impressive displacement to produce more powerful low frequency output than you would expect from a driver this small. Featuring a reinforced paper cone, stitched foam surround, extensive venting, cast aluminum frame, and massive motor assembly, the EXL-X6.2D is a pint-sized subwoofer with big output capabilities.

Key Features

  • Small size and high excursion to produce powerful bass while taking up minimum space
  • Dual 2 ohm voice coils allow a variety of wiring options for use with various amplifiers
  • High power handling and impressive displacement for powerful low frequency output
  • Reinforced paper cone and stitched surround ensures reliability under high stress
  • Extensive venting enables the 2" 4-layer voice coils to handle up to 400 watts RMS
Your Price: $119.95
+ FREE SHIPPING
Bulk Pricing
Out of Stock
Get Notified When Available

We'll send you an email when DS18 EXL-X6.2D 6-1/2" Cast Frame DVC Subwoofer 2 Ohm is back in stock or available for preorder.

Special order item, ships in 2-4 weeks.
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

DS18 EXL-X6.2D 6-1/2" Cast Frame DVC Subwoofer 2 Ohm

If you are short on space, but need more low frequency output, then the EXL-X6.2D 6-1/2" cast frame subwoofer from DS18 is the perfect solution. This compact subwoofer combines high power handling and excellent excursion capabilities to deliver remarkable output for its size. To improve reliability, the treated foam surround is stitched to the rigid reinforced paper cone eliminating a common failure point for many smaller high excursion drivers. For high power handling, the 4-layer 2" voice coils are wound on an aluminum former and vented extensively to dissipate heat while lowering power compression. The strong motor assembly consists of dual stacked magnets allowing ample voice coil clearance for high excursion without bottoming out. Holding everything together is a solid cast aluminum frame built to handle the stress of the difficult car audio environment. This rugged construction makes the EXL-X6.2D a powerful compact subwoofer that will take serious use and abuse while continuing to provide incredible performance.

The design of the EXL-X6.2D makes it suitable for a variety of designs. A sealed enclosure or infinite baffle installation will produce accurate and controlled low end for systems designed for sound quality. Vented enclosures will result in more output for higher SPL. Dual 2 ohm voice coils allow for a variety of wiring configurations to achieve maximum power from your amplifier.

Note: Specifications listed are with the voice coils wired in series for a 4 ohm load.

Product Details

BrandDS18
ModelEXL-X6.2D
Part Number294-8080
UPC810005180948
Unit of MeasureEach
Weight10

Product Specifications

Nominal Diameter6-1/2"
Bolt Circle Diameter6.33
Power Handling (RMS)400 Watts
Power Handling (MAX)800 Watts
Impedance
Frequency Response40 to 820Hz
Sensitivity84dB 2.83V/1m
Voice Coil Diameter2"

Thiele-Small Parameters

Resonant Frequency (Fs)76Hz
DC Resistance (Re)
Voice Coil Inductance (Le)9.35mH
Mechanical Q (Qms)6.416
Electromagnetic Q (Qes)1.04
Total Q (Qts)0.9
Compliance Equivalent Volume (Vas)0.07ft³
Mechanical Compliance of Suspension (Cms)0.06mm/N
BL Product (BL)16.097T·m
Diaphragm Mass Inc. Airload (Mms)78.6g
Maximum Linear Excursion (Xmax)10mm
Surface Area of Cone (Sd)158cm²

Materials of Construction

Cone MaterialPaper / Glass Fiber
Surround MaterialFoam
Voice Coil Wire MaterialAluminum
Voice Coil FormerAluminum
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter6.92"
Baffle Cutout Diameter5.78"
Depth4.25"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.3ft³
Sealed F371.7Hz
Vented Volume0.3ft³
Vented F352.7Hz
