• Home
  • Ciare CM100 4" Midrange 4 Ohm

Ciare CM100 4" Midrange 4 Ohm

CiarePart # 293-132
Model: CM100
Read 2 Reviews or

The Ciare CM100's solid build quality and advanced construction ensure that this midrange can handle high volumes without distortion, making it perfect for use in a wide range of applications. Its efficient and compact design makes it suitable for use in small to medium-sized speakers, as well as in automotive and marine audio systems.

Key Features

  • Large ferrite magnet for high sensitivity
  • Treated paper cone for smooth natural tonality
  • 60 watt power handling
Your Price: $43.73
MSRP: $58.30
Save $14.57 (25%)
Bulk Pricing
2 In Stock
Get Notified When Available

We'll send you an email when Ciare CM100 4" Midrange 4 Ohm is back in stock or available for preorder.

Ships next business day. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Ciare CM100 4" Midrange 4 Ohm

The Ciare CM100 4" Midrange is a high-quality speaker that delivers exceptional sound quality and power handling capabilities. This midrange features a 4-inch cone made from a high-strength paper material that provides a flat frequency response and excellent transient response. The driver also features a ferrite magnet, which provides a strong magnetic field in a durable and rugged design.

The CM100's sleek and modern design makes it a perfect complement to any home or professional sound system. Its lightweight and compact size make it easy to install and incorporate into any audio setup.

Whether you're a DIY audio enthusiast or a professional sound engineer, the Ciare CM100 4" Midrange is the perfect choice for any audio project that demands exceptional sound quality and power handling capabilities. If you're looking for a high-quality midrange that will take your audio experience to the next level, look no further than the Ciare CM100.

Product Details

BrandCiare
ModelCM100
Part Number293-132
UPC848864073149
Unit of MeasureEach
Weight1.6

Product Specifications

Nominal Diameter4"
Bolt Circle Diameter4.33
Power Handling (RMS)60 Watts
Power Handling (MAX)150 Watts
Impedance4Ω
Frequency Response150 to 8,000Hz
Sensitivity89dB 2.83V/1m
Voice Coil Diameter1"

Thiele-Small Parameters

Resonant Frequency (Fs)160Hz
DC Resistance (Re)3.4Ω
Voice Coil Inductance (Le)0.18mH
Mechanical Q (Qms)2.75
Electromagnetic Q (Qes)0.52
Total Q (Qts)0.43
Compliance Equivalent Volume (Vas)0.06ft³
Mechanical Compliance of Suspension (Cms)0.55mm/N
BL Product (BL)4.09T·m
Diaphragm Mass Inc. Airload (Mms)4g
Maximum Linear Excursion (Xmax)1.9mm
Surface Area of Cone (Sd)48cm²

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialCloth
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter3.96"
Baffle Cutout Diameter3.58"
Depth2.17"
# Mounting Holes4
