  • Beyma 8CX300Fe 8" Coaxial Loudspeaker 8+16 Ohm

NEW Beyma 8CX300Fe 8" Coaxial Loudspeaker 8+16 Ohm

Beyma
Part #253-099

NEW Beyma 8CX300Fe 8" Coaxial Loudspeaker 8+16 Ohm

Beyma
Part #253-099
Model: 8CX300Fe

The Beyma 8CX300Fe is an 8" coaxial transducer engineered for professional audio applications requiring a compact, high-performance driver with extended frequency response and precise directivity. Its integrated design combines a low-frequency driver and a high-frequency compression driver, making it suitable for applications such as studio monitors, compact PA systems, and high-fidelity installations.

Key Features
  • Covers an extensive frequency range from 90 Hz to 20 kHz​
  • Features a 2.5" (63.5 mm) voice coil for the low-frequency driver and a 1.75" (44.4 mm) voice coil for the high-frequency driver
  • Incorporates a shorting cap in the magnetic circuit to extend response and reduce distortion​
  • Utilizes a weatherproof cone with treatment on both sides for increased durability​
  • Equipped with a PM4 diaphragm in the high-frequency driver for improved sound quality​
  • Provides a 70º conical coverage pattern for controlled dispersion​
Similar items that may interest you:
See all items in Pro Coaxial Full-Range Speakers
NEW $268.50
+ FREE SHIPPING
MSRP: $358.00
Save $89.50 (25%)
Bulk Pricing

Back-Ordered

Expected back in stock any day
Alert Me When Available
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Beyma 8CX300Fe 8" Coaxial Loudspeaker 8+16 Ohm

8CX300Fe 8" Coaxial Loudspeaker 8+16 Ohm

The 8CX300Fe's substantial power handling capabilities and high sensitivity enable it to deliver clear and dynamic sound output, making it suitable for demanding audio applications. The 2.5" voice coil in the low-frequency driver and the 1.75" voice coil in the high-frequency driver enhance thermal stability, contributing to consistent performance over time. The inclusion of a shorting cap in the magnetic circuit extends the frequency response and reduces distortion, ensuring accurate sound reproduction. The weatherproof cone, treated on both sides, offers enhanced durability and reliability, even in challenging environmental conditions. The PM4 diaphragm in the high-frequency driver improves sound quality, while the 70º conical coverage pattern provides controlled dispersion, making it ideal for applications requiring precise directivity. Optimized for studio monitors, compact PA systems, and high-fidelity installations, this coaxial transducer offers versatility and exceptional performance for professional audio setups.​

Product Details

BrandBeyma
Model8CX300Fe
Part Number253-099
UPC8435469041820
Unit of MeasureEach
Weight10.8

Product Specifications

Nominal Diameter8"
Bolt Circle Diameter7.8
Power Handling (RMS)300 Watts
Power Handling (MAX)600 Watts
Impedance8Ω
Frequency Response90 to 20,000Hz
Sensitivity95dB 2.83V/1m
Voice Coil Diameter2.5"

Thiele-Small Parameters

Resonant Frequency (Fs)89Hz
DC Resistance (Re)5.2Ω
Voice Coil Inductance (Le)0.2mH
Mechanical Q (Qms)4.2
Electromagnetic Q (Qes)0.63
Total Q (Qts)0.55
Compliance Equivalent Volume (Vas)0.38ft³
Mechanical Compliance of Suspension (Cms)158mm/N
BL Product (BL)9.6T·m
Diaphragm Mass Inc. Airload (Mms)0.02g
Maximum Linear Excursion (Xmax)6mm
Surface Area of Cone (Sd)0.022cm²

Mounting Information

Overall Outside Diameter8.3"
Baffle Cutout Diameter7.1"
Depth4.9"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.247ft³
Sealed F3138.4Hz
Vented Volume0.705ft³
Vented F366.61Hz
