  • B&C FB354-16 2-Way 5,600 Hz Passive Crossover For DCX354-16 Coaxial Compression Driver

CLEARANCE B&C FB354-16 2-Way 5,600 Hz Passive Crossover For DCX354-16 Coaxial Compression Driver

B&C SpeakersPart # 294-6466
Model: FB35416

Enhance your audio system with the B&C FB354-16 2-Way 5,600 Hz Passive Crossover, designed specifically for the DCX354-16 Coaxial Compression Driver. This precision-engineered crossover completes the most accurate point source solution available, delivering flat high-fidelity response right out of the box using 100% OEM components. Ideal for use with the ME464 300Hz horn, the FB354 ensures seamless integration and outstanding performance.

Key Features

  • 2-way passive crossover designed for DCX354-16 coaxial compression driver
  • Phase aligns mid and high frequency elements for optimal sound
  • Asymmetrical slope crossover at 5.6kHz for flat response and minimal distortion
  • Series protection via industrial filament bulbs to prevent overpowering
  • Compatible with ME464 300Hz horn for comprehensive system integration
CLEARANCE $138.42
+ FREE SHIPPING
MSRP: $230.70
Save $92.28 (40%)
Bulk Pricing
1 In Stock
Get Notified When Available

We'll send you an email when B&C FB354-16 2-Way 5,600 Hz Passive Crossover For DCX354-16 Coaxial Compression Driver is back in stock or available for preorder.

Order in the next 1 hr 35 min to ship today. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

B&C FB354-16 2-Way 5,600 Hz Passive Crossover For DCX354-16 Coaxial Compression Driver

The FB354 crossover expertly phase aligns the mid and high-frequency elements of the DCX354, implementing an asymmetrical slope crossover at 5.6kHz. This design yields a flat response with no loss in sensitivity, ensuring balanced energy distribution between the two diaphragms and minimizing distortion across all output levels. The crossover frequency is carefully chosen to provide the best balance and clarity, making your audio system sound more natural and accurate.

For added protection, the FB354 includes industrial filament bulbs that act as series protection, preventing over-powering and maintaining consistent tonal balance even at very high output levels. This feature ensures the longevity and reliability of your audio system, safeguarding it against potential damage from excessive power.

Upgrade your audio experience with the B&C FB354-16 Passive Crossover, the perfect complement to the DCX354-16 Coaxial Compression Driver. Achieve unparalleled sound quality and performance, with the assurance of using components designed for precise compatibility and high-fidelity response.

Product Details

BrandB&C Speakers
ModelFB35416
Part Number294-6466
UPC8050593406842
Unit of MeasureEach
Weight0.85
