B&C 5CXN44 5" Professional Coaxial Speaker 80 X 80 8 Ohm

B&C SpeakersPart # 294-6049
Model: 5CXN44
2 Questions, 3 Answers or
The compact 5CXN44 5” coaxial speaker from B&C Speakers uses a neodymium LF/HF motor, polyimide diaphragm HF driver, and FEA-optimized design produce high output and minimal distortion. With remarkably smooth response and low distortion, this coaxial full-range driver is ideal for any high-fidelity home speaker, studio monitor, or portable system that needs to deliver high SPL.

Key Features

  • Compact size and high output capability is ideal for portable designs
  • Aluminum demodulating ring for minimal distortion with smooth midrange response
  • Powerful neodymium motor lowers weight without sacrificing quality
  • Waterproof treated paper cone is perfect for use in locations that may be exposed to harsh weather
Your Price: $206.94
+ FREE SHIPPING
MSRP: $344.90
Save $137.96 (40%)
Bulk Pricing
Back-Ordered
Get Notified When Available

We'll send you an email when B&C 5CXN44 5" Professional Coaxial Speaker 80 X 80 8 Ohm is back in stock or available for preorder.

Estimated back in stock 9/17/2025
Alert Me When Available
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

B&C 5CXN44 5" Professional Coaxial Speaker 80 X 80 8 Ohm

The low frequency driver portion of the 5CXN44 has been designed to produce extremely smooth and natural midrange response you expect from B&C drivers. The 1.7" voice coil is wound on a light-weight Kapton former to handle 150 watts RMS (300 watts peak). The high power handling gives this driver amazing output capability for its size. Also, with over 11 mm of peak-to-peak excursion capability, the 5CXN44 can move an impressive amount of air for surprising midbass impact. A rugged cast aluminum frame ensures that this little driver can take the use and abuse that it will be exposed to in the pro sound or even mobile audio environment. Finally, the naturally damped paper cone produces smooth response and even has a waterproof coating for use in less than ideal situations.

The 5CXN44's high frequency assembly has been engineered to be an easy match for the woofer. The 1.4" polymer dome produces extremely wide frequency response, making for an easy transition to the woofer. At 101 dB efficient (2.83V/1m) the high frequency unit only needs a small amount of attenuation to properly match up with the low frequency driver for flat response. It's controlled 80° conical dispersion pattern is perfect for filling a large area with sound while minimizing unwanted reflections. All of this makes the 5CXN44 one of the most capable small coaxial drivers on the market.

Specifications (Woofer): • Power handling: 150 watts RMS/ 300 watts continuous program • VC dia: 1.7" • Le: 0.37 mH • Impedance: 8 ohms • Re: 4.7 ohms • Frequency response: 70 – 5,000 Hz • Fs: 70 Hz • SPL: 86.5 dB 2.83V/1m • Vas: 0.15 cu. ft. • Qms: 9.6 • Qes: 0.47 • Qts: 0.45 • Xmax: 5.5 mm • Xvar: 6.0 mm.

Specifications (Compression driver): • Diaphragm: HT Polymer • Power handling: 25 watts RMS/ 50 watts continuous program (with recommended crossover of 2,000 Hz/12 dB slope) • VCdia: 1.4" • Impedance: 8 ohms • Frequency response: 2,000 – 18,000 Hz • SPL: 101 dB 2.83V/1m

Dimensions: • Outside diameter: 6.01" corner to corner • Cutout diameter: 4.8" • Depth: 3.78"

Product Details

BrandB&C Speakers
Model5CXN44
Part Number294-6049
UPC848864068589
Unit of MeasureEach
Weight3.65

Product Specifications

Nominal Diameter5"
Bolt Circle Diameter5.6
Power Handling (RMS)300 Watts
Impedance8Ω
Frequency Response70 to 18,000Hz
Sensitivity86.5dB 2.83V/1m
Voice Coil Diameter1.7"

Thiele-Small Parameters

Resonant Frequency (Fs)70Hz
DC Resistance (Re)4.7Ω
Voice Coil Inductance (Le)0.37mH
Mechanical Q (Qms)9.6
Electromagnetic Q (Qes)0.47
Total Q (Qts)0.45
Compliance Equivalent Volume (Vas)0.15ft³
Mechanical Compliance of Suspension (Cms)0.345mm/N
BL Product (BL)8.1T·m
Diaphragm Mass Inc. Airload (Mms)15g
Maximum Linear Excursion (Xmax)5.5mm
Surface Area of Cone (Sd)95cm²

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialRubber
Voice Coil Wire MaterialCopper
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialCast Aluminum
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter6.1"
Baffle Cutout Diameter4.8"
Depth3.78"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.07ft³
Sealed F3123.6Hz
Vented Volume0.18ft³
Vented F364.4Hz
