B&C 15NW76 15" Professional Neodymium Woofer 8 Ohm

B&C SpeakersPart # 294-5985
Model: 15NW76
2 Questions, 1 Answer or
B&C's 15NW76 is the driver of choice when you need heavyweight performance from a lightweight professional 15" speaker!

Key Features

  • Neodymium magnet is light but powerful
  • Ventilated voice coil gap reduces power compression
  • Aluminum demodulation ring reduces distortion
  • 1,200 watt continuous program power
  • 3" copper voice coil
  • 100.0 dB 1w/1m sensitivity
Your Price: $326.82
+ FREE SHIPPING
MSRP: $544.70
Save $217.88 (40%)
Bulk Pricing
Out of Stock
Get Notified When Available

We'll send you an email when B&C 15NW76 15" Professional Neodymium Woofer 8 Ohm is back in stock or available for preorder.

Ships in 7-10 Business Days
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

B&C 15NW76 15" Professional Neodymium Woofer 8 Ohm

The B&C Speakers 15NW76 15" neodymium driver offers great fidelity, smooth response, and outstanding efficiency in a well-engineered professional package. The 15NW76's very high power handling and Xmax capabilities make it suitable for any pro audio speaker enclosure, including horn loaded.

Product Details

BrandB&C Speakers
Model15NW76
Part Number294-5985
UPC848864009674
Unit of MeasureEach
Weight15.4

Product Specifications

Nominal Diameter15"
Bolt Circle Diameter14.7
Power Handling (RMS)1200 Watts
Impedance
Frequency Response40 to 2,000Hz
Sensitivity100dB 2.83V/1m
Voice Coil Diameter3"

Thiele-Small Parameters

Resonant Frequency (Fs)42Hz
DC Resistance (Re)
Voice Coil Inductance (Le)1.25mH
Mechanical Q (Qms)4.3
Electromagnetic Q (Qes)0.23
Total Q (Qts)0.22
Compliance Equivalent Volume (Vas)4.5ft³
BL Product (BL)25.5T·m
Diaphragm Mass Inc. Airload (Mms)104g
Maximum Linear Excursion (Xmax)8mm
Surface Area of Cone (Sd)855cm²

Materials of Construction

Cone MaterialCoated Paper
Voice Coil Wire MaterialCopper
Voice Coil FormerFiberglass
Basket / Frame MaterialCast Aluminum
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter15.5"
Baffle Cutout Diameter13.9"
Depth7"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.9ft³
Sealed F3161.2Hz
Vented Volume3.5ft³
Vented F343.3Hz
