B&C 15NW100 15" Neodymium Subwoofer Speaker Driver

B&C Speakers
Part #294-572

B&C 15NW100 15" Neodymium Subwoofer Speaker Driver

B&C Speakers
Part #294-572
Model: 15NW100
The B&C Speakers 15NW100 15" professional driver provides superb, reliable performance—even in extremely compact enclosures.
Key Features
  • Lightweight but powerful FEA-optimized neodymium magnet
  • Ventilated voice coil gap reduces power compression
  • Double silicone spider
  • 2,000 watt continuous program power
  • 4" copper voice coil on fiberglass former
  • 97 dB 1w/1m sensitivity
Your Price: $373.62
+ FREE SHIPPING
MSRP: $622.70
Save $249.08 (40%)
Bulk Pricing
Order in the next 1 hr 53 min to ship today. Details

Only 3 In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

B&C 15NW100 15" Neodymium Subwoofer Speaker Driver

The B&C 15NW100 is an advanced, lightweight subwoofer driver featuring 1,000 watts RMS power handling, a 1" long/4" diameter copper voice coil with very high thermal capability, and a ventilated neodymium magnet assembly that provides low power compression.

Product Details

BrandB&C Speakers
Model15NW100
Part Number294-572
UPC844632086090
Unit of MeasureEach
Weight22.3

Product Specifications

Nominal Diameter15"
Bolt Circle Diameter14.7
Power Handling (RMS)2000 Watts
Impedance8Ω
Frequency Response35 to 1,500Hz
Sensitivity97dB 2.83V/1m
Voice Coil Diameter4"

Thiele-Small Parameters

Resonant Frequency (Fs)33Hz
DC Resistance (Re)5.1Ω
Voice Coil Inductance (Le)1.9mH
Mechanical Q (Qms)4.3
Electromagnetic Q (Qes)0.23
Total Q (Qts)0.22
Compliance Equivalent Volume (Vas)4.9ft³
BL Product (BL)28T·m
Diaphragm Mass Inc. Airload (Mms)173g
Maximum Linear Excursion (Xmax)9mm
Surface Area of Cone (Sd)855cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialCloth
Voice Coil Wire MaterialCopper
Voice Coil FormerFiberglass
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter15.5"
Baffle Cutout Diameter13.9"
Depth7.1"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume1ft³
Sealed F3126.9Hz
Vented Volume3.5ft³
Vented F334.7Hz
