Aurum Cantus AC-200MKII 8" Carbon Fiber Sandwich Woofer

Aurum Cantus
Part #296-420

Aurum Cantus AC-200MKII 8" Carbon Fiber Sandwich Woofer

Aurum Cantus
Part #296-420
Model: AC-200MK2
The AC-200MKII utilizes a special non-woven carbon fiber sandwich cone with foam core for light weight and extreme rigidity. A high-power motor offers exceptional cone control, high sensitivity, and substantial power handling.
Key Features
  • Multi-layer composite non-woven carbon fiber cone
  • Heavy-duty chassis, vented pole and extended back plate
  • Large magnet and high-power motor structure
Your Price: $173.98
+ FREE SHIPPING
MSRP: $230.99
Save $57.01 (25%)
Bulk Pricing
Quantity:Qty: 1-3 $173.98/ea
Quantity:Qty: 4+$159.76/ea
Order in the next 0 hr 32 min to ship today. Details

Only 3 In Stock

More due on 6/14/2025
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Aurum Cantus AC-200MKII 8" Carbon Fiber Sandwich Woofer

Aurum Cantus midwoofers feature high-performance cone materials, long-excursion designs, and high quality construction. The AC-200MKII utilizes a special non-woven carbon fiber sandwich cone with foam core for light weight and extreme rigidity. A high-power motor offers exceptional cone control, high sensitivity, and substantial power handling.

Product Details

BrandAurum Cantus
ModelAC-200MK2
Part Number296-420
UPC844632003325
Unit of MeasureEach
Weight8.62

Product Specifications

Nominal Diameter8"
Power Handling (RMS)150 Watts
Power Handling (MAX)225 Watts
Impedance8Ω
Frequency Response25 to 3,500Hz
Sensitivity90dB 2.83V/1m
Voice Coil Diameter2"

Thiele-Small Parameters

Resonant Frequency (Fs)25Hz
DC Resistance (Re)7Ω
Voice Coil Inductance (Le)0.67mH
Mechanical Q (Qms)3.99
Electromagnetic Q (Qes)0.25
Total Q (Qts)0.23
Compliance Equivalent Volume (Vas)3.81ft³
Mechanical Compliance of Suspension (Cms)1.59mm/N
BL Product (BL)10.6T·m
Diaphragm Mass Inc. Airload (Mms)29.2g
Maximum Linear Excursion (Xmax)8mm
Surface Area of Cone (Sd)220cm²

Materials of Construction

Cone MaterialCarbon Fiber
Voice Coil Wire MaterialCCA
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter8.74"
Baffle Cutout Diameter7.17"
Depth4.02"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.4ft³
Sealed F386Hz
Vented Volume0.75ft³
Vented F344.1Hz
