CLEARANCE Aurasound NS2x3-184-4A 2" x 3" Extended Range Driver 4 Ohm

AuraSoundPart # 296-256
Model: NS2x3-184-4A
Aurasound designed the 2" x 3" full-range NS2x3 driver with bleeding edge loudspeaker technology for the highest quality, full-range sound, in the smallest possible package. Great for modern applications such as speaker bars, desktop computer speakers, thin tower speakers, and line arrays.

Key Features

  • NRT radial neodymium motor for extremely low distortion
  • Underhung motor for great frequency response linearity
  • Small frame size for reduced center-to-center distance and reduced comb filtering when used in arrays
  • Great for modern audio applications including sound bars and ultra-thin tower speakers
Get Notified When Available

We'll send you an email when Aurasound NS2x3-184-4A 2" x 3" Extended Range Driver 4 Ohm is back in stock or available for preorder.

60 Day No Hassle Return Policy

Overview

Aurasound NS2x3-184-4A 2" x 3" Extended Range Driver 4 Ohm

The Aurasound NS2x3-184-4A 2" x 3" full-range driver is packed with next-gen speaker technology. An NRT™ neodymium radial magnet motor submerses the 18.4 mm, underhung voice coil in magnetic flux for supreme control, low distortion, high output (for its size), and wide frequency range without stray magnetic fields that could potentially damage sensitive electronics, while the extreme venting provided by a capless pole piece evacuates air that would otherwise be compressed (in a driver this size).

A paper cone is mated to a rubber impregnated cloth surround to reduce cone breakup, for an extremely linear frequency response from 200 to 20,000 Hz. The low, 220 Hz free air resonance allows for low crossover points, meaning you can pair the NS2x3-164-4A with nearly any woofer up to 5 feet away (2-1/2 ft. is the recommended maximum) seamlessly.

Product Details

BrandAuraSound
ModelNS2x3-184-4A
Part Number296-256
UPC848864016245
Unit of MeasureEach
Weight0.34

Product Specifications

Nominal Diameter2 x 3"
Power Handling (RMS)7 Watts
Power Handling (MAX)15 Watts
Impedance4Ω
Frequency Response200 to 20,000Hz
Sensitivity84dB 2.83V/1m
Voice Coil Diameter0.72"

Thiele-Small Parameters

Resonant Frequency (Fs)220Hz
DC Resistance (Re)3.5Ω
Mechanical Q (Qms)4.9
Electromagnetic Q (Qes)1.9
Total Q (Qts)1.38
Compliance Equivalent Volume (Vas)0.01ft³
Mechanical Compliance of Suspension (Cms)0.41mm/N
BL Product (BL)1.8T·m
Diaphragm Mass Inc. Airload (Mms)1.26g
Maximum Linear Excursion (Xmax)0.43mm
Surface Area of Cone (Sd)25.72cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialCloth
Voice Coil Wire MaterialCCA
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialSteel
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter1.97" x 3.54"
Baffle Cutout Diameter1.73" x 3.31"
Depth1.55"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.00744ft³
Sealed F3230.6Hz
Vented Volume0.11ft³
Vented F3142.5Hz
