  • 80PG7WA 3" Green-Cone Full-Range Speaker 16 Ohm

BUYOUT 80PG7WA 3" Green-Cone Full-Range Speaker 16 Ohm

Read 1 Review or
Factory Buyouts
Part #299-4342

BUYOUT 80PG7WA 3" Green-Cone Full-Range Speaker 16 Ohm

Factory Buyouts
Part #299-4342
Model: 80PG7WA
Read 1 Review or

The 80PG7WA 3" Green-Cone Full-Range Speaker utilizes a one-piece paper cone and surround, neodymium magnet and 16 ohm impedance.

Key Features
  • 16 ohm impedance
  • Unique green-colored cone
  • Neodymium magnet for a small, lightweight stature
BUYOUT $0.88
Bulk Pricing
Quantity:Qty: 1-49 $0.88/ea
Quantity:Qty: 50-99 $0.78/ea
Quantity:Qty: 100+$0.68/ea
Order in the next 0 hr 52 min to ship today. Details

6793In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

80PG7WA 3" Green-Cone Full-Range Speaker 16 Ohm

The 80PG7WA 3" Green-Cone Full-Range Speaker utilizes a one-piece paper cone and surround, neodymium magnet and 16 ohm impedance. With an extended response and unique green-colored cone, this would be a great candidate for use in multiples.

Product Details

BrandFactory Buyouts
Model80PG7WA
Part Number299-4342
UPC848864074146
Unit of MeasureEach
Weight0.15

Product Specifications

Nominal Diameter3"
Power Handling (RMS)1.6 Watts
Power Handling (MAX)3.2 Watts
Impedance16Ω
Frequency Response200 to 12,000Hz
Sensitivity81.41dB 2.83V/1m
Voice Coil Diameter0.5"

Thiele-Small Parameters

Resonant Frequency (Fs)193Hz
DC Resistance (Re)15.55Ω
Mechanical Q (Qms)9.419
Electromagnetic Q (Qes)8.104
Total Q (Qts)4.356
Compliance Equivalent Volume (Vas)0.0356ft³
Diaphragm Mass Inc. Airload (Mms)0.8639g
Maximum Linear Excursion (Xmax)0.25mm
Surface Area of Cone (Sd)30.19cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialPaper
Voice Coil Wire MaterialCopper
Voice Coil FormerPaper
Basket / Frame MaterialSteel
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter3.0625"
Baffle Cutout Diameter2-13/16"
Depth1"
