We'll send you an email when 5009574EO1 2-1/4" 1W Paper Cone Mini Speaker 8 Ohm is back in stock or available for preorder.
Product Details | |
|---|---|
| Brand | Coast Buyouts |
| Model | 5009574EO1 |
| Part Number | 299-4168 |
| UPC | 848864073316 |
| Unit of Measure | Each |
| Weight | 0.1 |
Product Specifications | |
|---|---|
| Nominal Diameter | 2" |
| Power Handling (RMS) | 1 Watts |
| Power Handling (MAX) | 2 Watts |
| Impedance | 8Ω |
| Frequency Response | 500-15,000Hz |
| Sensitivity | 81.92dB 2.83V/1m |
| Voice Coil Diameter | 0.5" |
Thiele-Small Parameters | |
|---|---|
| Resonant Frequency (Fs) | 500.4Hz |
| DC Resistance (Re) | 7.488Ω |
| Mechanical Q (Qms) | 6.776 |
| Electromagnetic Q (Qes) | 10.45 |
| Total Q (Qts) | 4.11 |
| Compliance Equivalent Volume (Vas) | 0.0029ft³ |
| Diaphragm Mass Inc. Airload (Mms) | 0.4283g |
| Surface Area of Cone (Sd) | 15.9cm² |
Materials of Construction | |
|---|---|
| Cone Material | Paper |
| Surround Material | Paper |
| Voice Coil Wire Material | Copper |
| Voice Coil Former | Paper |
| Basket / Frame Material | Steel |
| Magnet Material | Neodymium |
Mounting Information | |
|---|---|
| Overall Outside Diameter | 2.25" |
| Baffle Cutout Diameter | 2" |
| Depth | 0.75" |
