BUYOUT 1208PB-088A 3" x 5" 5W Paper Cone Speaker 8 Ohm

Factory Buyouts
Part #299-4172

BUYOUT 1208PB-088A 3" x 5" 5W Paper Cone Speaker 8 Ohm

Factory Buyouts
Part #299-4172
Model: 1208PB088A
The 1208PB-088A 3" x 5" Speaker uses a paper cone and cloth surround to produce natural full-range response from 150 to 15,000 Hz. Thanks to the powerful shielded motor this driver has excellent efficiency for its size.
Key Features
  • Shielded magnet assembly is suitable for use near sensitive electronics
  • Perfect for use in slim designs such as sound bars and portable speakers
  • Flat mounting flange for simple front or rear mount installation
  • Perfect for use in slim designs such as sound bars and portable speakers
BUYOUT $2.88
Bulk Pricing
Quantity:Qty: 1-29 $2.88/ea
Quantity:Qty: 30-59 $2.56/ea
Quantity:Qty: 60+$2.45/ea
Order in the next 4 hr 11 min to ship today. Details

894In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

1208PB-088A 3" x 5" 5W Paper Cone Speaker 8 Ohm

The 1208PB-088A 3" x 5" Speaker has a 5" x 3" mounting flange allowing it to easily fit in slim speaker designs. This driver uses a fully shielded motor for use near devices that are sensitive to stray magnetic fields. This driver can produce an impressive amount of output for its size making it perfect for designs such as speaker bars, TV speakers, and portable Bluetooth enabled projects.

Product Details

BrandFactory Buyouts
Model1208PB088A
Part Number299-4172
UPC848864073330
Unit of MeasureEach
Weight0.35

Product Specifications

Power Handling (RMS)4 Watts
Power Handling (MAX)8 Watts
Impedance8Ω
Frequency Response150 - 15,000Hz
Sensitivity81.58dB 2.83V/1m
Voice Coil Diameter0.5"

Thiele-Small Parameters

Resonant Frequency (Fs)152Hz
DC Resistance (Re)7.712Ω
Voice Coil Inductance (Le)0.203mH
Mechanical Q (Qms)5.325
Electromagnetic Q (Qes)4.869
Total Q (Qts)2.543
Compliance Equivalent Volume (Vas)0.045ft³
Diaphragm Mass Inc. Airload (Mms)1.981g
Surface Area of Cone (Sd)40.72cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialCloth
Voice Coil Wire MaterialCopper
Voice Coil FormerPaper
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Depth1.75"
# Mounting Holes4
