BUYOUT 10" 1025 Ribbed Paper Cone Woofer 8 ohm

Factory BuyoutsPart # 299-4184
The 10" 1025 Ribbed Paper Cone Woofer is a heavy-duty replacement, upgrade or inexpensive alternative for your next custom speaker project.

Key Features

  • Classic ribbed paper cone for smooth, uncolored bass
  • Long-throw voice coil allows for over 4.5mm of one-way linear Xmax
  • Large 1.5" diameter, 2-layer voice coil for 60W RMS power handling
BUYOUT $14.88
Bulk Pricing
Quantity:Qty: 1-9 $14.88/ea
Quantity:Qty: 10-19 $12.88/ea
Quantity:Qty: 20+ $10.88/ea
1071 In Stock
Get Notified When Available

We'll send you an email when 10" 1025 Ribbed Paper Cone Woofer 8 ohm is back in stock or available for preorder.

Order in the next 6 hr 20 min to ship today. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

10" 1025 Ribbed Paper Cone Woofer 8 ohm

The 10" 1025 Ribbed Paper Cone Woofer is a heavy-duty replacement, upgrade or inexpensive alternative for your next custom speaker project. The ribbed paper cone is exceptionally rigid yet light weight, while the oversize spider and long, 2-layer voice coil keep things moving smoothly.

A foam surround helps eliminate unwanted resonances and keeps excursion clean, while a sturdy 6-spoke steel frame holds everything together. This woofer is ideally suited for sealed enclosures.

Product Details

BrandFactory Buyouts
Part Number299-4184
UPC848864073392
Unit of MeasureEach
Weight3.3

Product Specifications

Nominal Diameter10"
Bolt Circle Diameter9.75
Power Handling (RMS)60 Watts
Power Handling (MAX)120 Watts
Impedance8Ω
Frequency Response30 - 1,500Hz
Sensitivity84.65dB 2.83V/1m
Voice Coil Diameter1.5"

Thiele-Small Parameters

Resonant Frequency (Fs)34.96Hz
DC Resistance (Re)7.348Ω
Voice Coil Inductance (Le)0.7893mH
Mechanical Q (Qms)3.754
Electromagnetic Q (Qes)2.724
Total Q (Qts)1.579
Compliance Equivalent Volume (Vas)4.244ft³
Diaphragm Mass Inc. Airload (Mms)30.18g
Maximum Linear Excursion (Xmax)4.75mm
Surface Area of Cone (Sd)353cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialFoam
Voice Coil Wire MaterialCopper
Voice Coil FormerAluminum
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter10.125"
Baffle Cutout Diameter9.125"
Depth4.125"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume1.2ft³
Sealed F353Hz
