Dayton Audio UM18-22 18" Ultimax DVC Subwoofer 2 ohms Per Coil

Brand:|Model: UM18-22|Part # 295-518


Dayton Audio’s Ultimax Series DVC subwoofers are purpose-built to move tons of air and create clean, articulate, fast bass. Experience the apex of subwoofer design!
In Stock
List Price$363.99
You Save23%
Your Price
$279.90
Buy 4+$266.65
Dayton Audio Baseball Cap
Qty: 1Part # 520-308
List Price:$19.99

*Domestic US orders only
Part # 295-518
Highlights
  • 18" design for enormous air movement
  • Over 2" of total cone travel!
  • 1000 watts RMS power handling
  • Dual mirror-imaged linear spiders ensure distortion-free excursion
  • Dual 2 ohm, 2-layer copper voice coils
  • Large vented pole piece and under-spider venting




Product Details

Dayton Audio UM18-22 18" Ultimax DVC Subwoofer 2 ohms Per Coil


If you want outrageous amounts of bass, you gotta move some air

With the UM18-22 Ultimax 18" driver, Dayton Audio has taken everything about the respected Dayton Audio Ultimax subwoofers to the extreme! Providing over 2" of peak-to-peak excursion, the Ultimax 18 sweeps over six liters of air with each stroke! Truly not for the faint of heart!

An audio bulldozer with the finesse of a sports car

Like the rest of the Ultimax series, the UM18-22 plays it clean, low, fast, and LOUD. Designed to excel in either sealed or vented enclosures, it features an ultra-powerful triple stack of high-grade ferrite ceramic magnets for ultra-high force and exceptional control, plus dual aluminum shorting rings above and below the magnetic gap for minimized inductance, "faster"-sounding bass response, and perfect magnetic symmetry. The voice coil diameter has been increased to 3 inches, for even more thermal dissipation area that allows the 18" model to withstand 1,000 watts of punishing bass power continuously without thermal fatigue. Dual 2-ohm voice coils allow for stereo 2 ohm operation, or mono operation in 1 ohm or 4 ohm configurations, for true design flexibility.

Built to produce massive low frequency output and keep on doing it

The huge 18" Nomex honeycomb composite curved cone features woven fiberglass outer skins for the ultimate in rigidity and resistance to damage, while the "tall-boy" rubber surround with integral gasket supports extreme stroke with linearity and durability. Dual 8" spiders are mirror-imaged, to keep the 2" of excursion completely linear and provide cancellation of distortion due to compliance asymmetry, for ultra-low mechanical distortion even at the outer limits of travel. And it's all held in perfect alignment by a rigid cast aluminium 12-spoke frame, for stability in any mounting position.

Put your home's construction to the test with the phenomenal bass output of this 18" beast!


Car audio recommended alignments:

    • Sealed 3 cubic ft. (net internal, not including driver) for an f3 of 32 Hz with a Qtc of .78
    • Vented 4 cubic ft. (net internal, not including driver or vent ) tuned to 22 Hz, with 2 flared vents 4" diameter by 32" long, for an f3 of 24 Hz

Home theater/stereo recommended alignments

    • Sealed (home theater/music): 4 cubic ft. (net internal, not including driver) for an f3 of 31 Hz, f10 of 18 Hz with a Qtc of 0.72
    • Sealed (music): 7 cubic ft. (net internal, not including driver) for an f3 of 31 Hz, f10 of 15.8 Hz with a Qtc of 0.62
    • Vented (home theater): 8 cubic ft. (net internal, not including driver or vent) tuned to 20 Hz, with 3 flared vents 4" diameter by 28.5" long, for an f3 of 18 Hz
    • Vented (infra-sub): 12 cubic ft. (net internal, not including driver or vent) tuned to 15.5 Hz, with 3 flared vents 4" diameter by 32" long, for an f3 of 15 Hz
    • Infinite Baffle: Approved (reaction force cancellation recommended )

Note: All specifications are derived with voice coils wired in series.



Product Specifications
  • Nominal Diameter18"
  • Power Handling (RMS)1,000 Watts
  • Power Handling (max)2,000 Watts
  • Impedance4 ohms
  • Frequency Response19 to 500 Hz
  • Sensitivity88.6 dB 2.83V/1m
  • Voice Coil Diameter3"
Thiele-Small Parameters
  • Resonant Frequency (Fs)19.50 Hz
  • DC Resistance (Re)4.4 ohms
  • Voice Coil Inductance (Le)2.22 mH
  • Mechanical Q (Qms)3.82
  • Electromagnetic Q (Qes)0.62
  • Total Q (Qts)0.53
  • Compliance Equivalent Volume (Vas)7.49 ft.³
  • Mechanical Compliance of Suspension (Cms)0.10 mm/N
  • BL Product (BL)23.8 Tm
  • Diaphragm Mass Inc. Airload (Mms)655g
  • Maximum Linear Excursion (Xmax)22 mm
  • Surface Area of Cone (Sd)1,219 cm²
Materials of Construction
  • Cone MaterialNomex / Glass Fiber
  • Surround MaterialRubber
  • Voice Coil FormerAluminum
  • Basket / Frame MaterialCast Aluminum
  • Magnet MaterialFerrite
Mounting Information
  • Overall Outside Diameter18.24"
  • Baffle Cutout Diameter16.75"
  • Depth9"
  • Bolt Circle Diameter17.40"
  • # Mounting Holes8
Optimum Cabinet Size (determined using BassBox 6 Pro High Fidelity suggestion)
  • Sealed Volume4.22 ft.³
  • Sealed F331 Hz
  • Vented Volume11.79 ft.³
  • Vented F316 Hz
Dayton Audio UM18-22 18" Ultimax DVC Subwoofer 2 ohms Per Coil
  • BrandDayton Audio
  • ModelUM18-22
  • Part Number295-518
  • UPC848791001062
  • Product CategorySubwoofer Drivers
  • Unit of MeasureEA
  • Product Rating
    (16 Reviews)
  • Weight44.3000 lbs.
